BUILDING FAÇADE CLADDING
Mbond® Aluminium Composite Panel (Mbond® ACP) is composed of a layered-type of Polyethylene Plastic (PE) core that firmly bonds between two aluminium sheets. The surface of the aluminium sheet is coated with PPG KYNAR 500 PVDF resin for sleek colour quality and higher chemical resistance. Mbond® ACP products have been tested at SIRIM QAS International Sdn Bhd and successfully acquired MS2571: 2017 standard.
SPECIFICATION
Panel Thickness: 4.0MM
Aluminium Coil Thickness: Range from 0.08mm to 0.5mm
Standard Width: 1.25M / 1.22M
Minimum Length: 1.22M
Maximum Length: 12.2M
- Subject to thickness tolerance
- Colour for reference only, order based on sealed sample
- Standard Product are available based on ex-stock basic
- Non-Standard Product (length, thickness, colour) are available subject to minimum order quantity
High Strength
Perfect Flatness
High Rigidity
Bendable
Polyvinylidene Fluoride (PVDF-PPG) Kynar 500 Resin
Highly non-reactive Thermoplastic Fluoropolymer with good resistance to solvent and acid bases
COLOR CHART
*Measurement subject to tolerance
*Above stock code for reference only
Please feel free for inquiry for the any of the above stock code needed
CERTIFICATE & Reports
MEchanical properties
| Report No: 2018CE1583 | Flexural Strength | MS 2571: 2017- Clause 6.4 Performance | 224.81 |
| Bending Elastic Modulus | MS 2571: 2017- Clause 6.4 Performance | 11.7 x 104 | |
| Breakthrough Resistance | MS 2571: 2017- Clause 6.4 Performance | 9.3 | |
| Shear Strength | MS 2571: 2017- Clause 6.4 Performance | 74.0 | |
| Peeling Strength | MS 2571: 2017- Clause 6.4 Performance | 124.28 |
Artificial Weathering Aging Resistance
Cyclic Corrosion Testing
Thermal Distortion Temperature
TEST REPORT & CERTIFICATE
| COUNTRY | TEST LAB | TEST STANDARD | RESULT | TEST REPORT | CERTIFICATE |
| MALAYSIA | SIRIM | MS2571:2017 | PASSED | ||
| CIDB PPS |
APPLICATION
— Architecture Façade Cladding
— Curtain Wall
— Curved Exterior Bullnose and Various Design to Architecture Desire
— Column Cover
— Beam Warping
— Boutique Façade Decoration
— Structure Finishing Cover
Bold never blends! Arm your façade with a personality and character to tell stories and reach heights. Mbond® PVPF-PE is flexible, has high rigidity and strength to help you actualise your unique statement and stand out.
INSTALLATION
Mbond® Aluminium Composite Panel (Mbond ACP) must be installed in a uniform direction to avoid colour shade refection differences as printed on all Mbond® MBC series protective firm. Kindly refer to illustration graph.
Mbond® ACP Series is laminated with a layer of PE base protective film its highly recommended to be removed as soon as installation is completed with no more than 60 days to avoid glue to residue on the surface of the panel due to direct exposure to sun and humid weather conditions.
