Aluminium Composite Panel roofs for buildings are widely used due to its durability in terms of weather and stain resistance, hassle-free maintenance, safety features, cost effectiveness and easy installation.
MBS
It’s thicker with elevated quality! MBS is commonly applicable for building exteriors, interiors and roofing purposes.
The material is built by inserting a soft, shock-absorbent core (typically plastic) layered between two layers of thick aluminium sheet metal. The purpose of this is to combine the shock-absorbing qualities of the soft inner core while the lightweight but relatively durable outer aluminium protects it.
UNI-S
Flexible to suit your roofing needs! UNI-S is widely used for building exteriors,
interiors and roofing purposes.
It is built by inserting a soft, shock absorbent core (typically plastic) layered between two layers of aluminium sheet metal. The purpose of this is to combine the shock-absorbing qualities of the soft inner core while the lightweight but relatively durable outer aluminium protects it. And one of its main uses is as an Aluminium Composite Panel roof for buildings.
Easy & Fast Installation
Colour Uniformity
Flatness
Light Weight
heatproof
Flexible
waterproof
Reduce Thermal Transfer
Standard Width: 1.22M
Thickness: 4mm
Standard Length: 1.22M / 1.83M /2.44M / 3.05M / 3.66M / 4.27M / 4.88M / 5.49M / 6.10M / 6.71M / 7.32M / 7.93M
— Roofing
— Glazing Pergolas
— Car Porches
— Canopy Panel
— Walkway
— Overhead Bridge & etc
MBOND – COLOR CHART
*Measurement subject to tolerance
*Above stock code for reference only
Please feel free for inquiry for the any of the above stock code needed
INSTALLATION METHOD
MBOND® Aluminium Composite Panel (Mbond ACP) is produced with a protective PE film on one or both sides which should be kept on until the panel is fastened.
To install, 50mm of protective film should be peeled off from the edges of the sheet to allow clean sheet insertion into the glazing system.
The residual film should be removed immediately after the glazing is completed.
Make sure the support structure is clean and dry. Do not directly screw the sheet, only use aluminium clapping for joining. Must leave a gal of at least 5mm in between sheets for thermal expansion and contraction. A minimum slope of 5º roof pitch is recommended to allow adequate rain water run-off.
MBond® Aluminium Composite Panel can be cold-form by : –
* a/b >= 2
* Ø < 90˚
* R >= 180t
MAINTENANCE & STOPRAGE GUIDELINES
STORAGE
Sheets should be kept indoor, protected from sunlight and rain fall by an appropriate opaque waterproof roof cover.
CLEANING METHOD
Use only neutral detergent or mild soap for cleaning. Wash by using soft cloth op sponge. Rinse off with lukewarm water (below 60˚C).
CUTTING METHOD
Use circular saw blade for cutting MBOND® Aluminium Composite Panel.
